EasyWagon
The tailor-made wagon hire service
Adriafer, in cooperation with VTG Rail Europe and the Trieste port community, provides its stakeholders, stakeholders and railway companies operating in the region with a wagon hire service that is unique in Italy.
Our wagons
Thanks to this project, any rail carrier or intermodal operator will have access to a wagon pool EVEN FOR A SINGLE DAY:
TWIN WAGONS
Ideal for transporting containers, semi-trailers or swap bodies.
80' wagons
Ideal for transporting 20′ and 40′ containers.
90' WAGONS
Ideal for loading almost all types of containers and 13.6 m swap bodies.
Sdggmrs(s) – TWIN
Technical Specifications
Sdggmrs(s) – TWIN
Technical Specifications
TARE WEIGHT
MAX. 35.5 T
⎯
MAX. LOAD
99.5 T
⎯
AXLE LOAD
22.5 T
⎯
MIN. DRIVABLE TURNING RADIUS
150 M
⎯
MAX. SPEED
120 KM/H
⎯
LOADING LENGTH
Max. 2 x 15,761 mm
or 4 x 7,820 mm – swap bodies (C782)
⎯
LOADING HIGHT ABOVE TOP OF RAIL, UNLOADED
270 mm for trailer
1.155 mm for swap bodies and containers
⎯
POKET WIDTH
2.700 mm
⎯
LOADING WIDTH
2.600 mm for Container
⎯
Sggrs(s) 80’
Technical Specifications
Sggrs(s) 80’
Technical Specifications
TARE WEIGHT
MAX. 28 T
⎯
MAX. LOAD
107 T
⎯
AXLE LOAD
22.5 T
⎯
MIN. DRIVABLE TURNING RADIUS
150 M
⎯
MAX. SPEED
120 KM/H
⎯
LOADING LENGTH
2 x 12.370 MM
⎯
LOADING HIGHT ABOVE TOP OF RAIL, UNLOADED
1.155 MM
⎯
POKET WIDTH
2.600 MM
⎯
LOADING WIDTH
2.600 MM
⎯
Sggmrs(s) 90’
Technical Specifications
Sggrs(s) 80’
Technical Specifications
TARE WEIGHT
MAX. 29 T
⎯
MAX. LOAD
106 T
⎯
AXLE LOAD
22.5 T
⎯
MIN. DRIVABLE TURNING RADIUS
150 M
⎯
MAX. SPEED
120 KM/H
⎯
LOADING LENGTH
2 x 13.820 MM
⎯
LOADING HIGHT ABOVE TOP OF RAIL, UNLOADED
1.155 MM
⎯
LOADING WIDTH
2.600 MM
⎯
- Location: Porto Franco Nuovo – Raccordo interno
- Availability: 20 wagons
- Fee: 77.00€/day undivided
- Location: Porto Franco Nuovo – Raccordo interno
- Availability: 24 wagons
- Fee: 52.00€/day undivided
- Location: Cervignano Freight Village – Deviatoio 206b
- Availability: 16 wagons
- Fee: 52.00€/day undivided
Conditions and Fees
These documents regulate the services for wagon and wagon hire activities and related ancillary activities carried out by Adriafer Rail Services S.r.l.
Download documents
Form di contatto Easy Wagon
"*" indicates required fields
Contact us via e-mail:
easywagon@adriaferrailservices.com
Or via phone at:
+39 331 133 3560
